With its polygonal shape, this tent offers a unique and versatile design. It can be customized to fit various spaces and requirements, making it suitable for a wide range of events and functions.
Our big clear span tent is made of aluminum alloy profiles and double coated PVC fabric.
We use the hot-dip galvanized steel connectors, and each bay are scalable, with max wind load up to 100-120 km/hour, and snow load up to 1.9kn/㎡.
It is prefabricated modular design structure which enables short installation period, easy to assembly and disassembly.
Also, a full range of accessories are optional to make it more multi-functional, such as ceiling lining, curtain, glass walls, ABS walls, sandwich walls, glass door, sliding door, rolling door, flooring system, rain gutter system and etc.
1.Frame material: high-anodized aluminum alloy 6061/T6,anti-rust surface.
2.Cover material: double PVC-coated fabric, tear-resistance, flame retardant, waterproof.
3.Advantage: Quick Setup, Movable, Safe Structure, 15-20 years lifespan, free installation guidance, free after-sales services, engineer support.
| Span Width | Side Height | Ridge Height | Bay Distance | Main Profile |
| 15m | 4m | 6.4m | 5m | 166x88x3mm |
| 18m | 4m | 6.9m | 5m | 166x88x3mm |
| 19m | 4m | 7m | 5m | 166x88x3mm |
| 20m | 4m | 7.2m | 5m | 204x110x4mm |
| 22m | 4m | 7.6m | 5m | 204x110x4mm |
